C16B3
Circuit breaker basic frame, ComPacT NSX160B, 25kA at 415VAC 50/60 Hz, 160A, without trip unit, 3 poles
Available on backorder
Add to Quote Basket
Choose all components required for your project
Request Quote
Our sales team works on your request to prepare a custom quote.
Get Quote in 24 Hours
We send you the best prices you can find in all of UAE within 24 hours.
Place the Order
Make your payment with direct bank transfer and place the order.
This is a 3 poles basic frame for ComPacT NSX160B. ComPacT NSX is designed to optimize space and breaking capacity for all standard and specific applications. This basic frame comes without trip unit, and is compatible with any type of trip unit which has to be ordered separately The breaking capacity Icu is 25kA at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz (limited to 440VAC 50/60Hz if there is an earth-leakage protection). It can be equipped with a variety of optional functions and accessories. The dimensions are 105mm x 161mm x 86mm. It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX160B is part of Schneider Electric EcoStruxure Power architecture.
C16B3
